Product introduction

0～3m IP68 low dielectric constant liquid guided wave wave radar level transmitter

The guided wave radar level transmitter is used for liquids, solid particles and small-sized oil tanks, all kinds of conductive and non-conductive mediums, such as coal bunkers, ash bins, oil tanks and etc. Guided wave radar level transmitter offers continuous measurement of the level of liquids, particles and slurries. The measurement won’t be affected by the medium type, temperature, inert gas, steam, dust, foam and so on. The accuracy could reach 3mm, the measuring range can be 3 meters, high temperature resistance could be 250 centigrade and high pressure resistance can be 20 kgs.

Apparent dimension

Application case

HCDAR-56 is a coaxial guided wave antenna structure. Due to the guided wave wave tube structure, when the measured medium fluctuates greatly, the guided wave tube isolates it and the internal fluctuation is small. It is suitable for the measurement of liquid with large surface fluctuation, and the enhanced signal transmission of coaxial structure is also suitable for the measurement of liquid with low dielectric constant.

Technical data
