HCDAR-66 Water Tank Level sensor

Application: Liquid，Slurry，Dew Occasions
Measuring Range: 0～20m
Connection Process: Flange
Medium Temperature :（-40～120）℃
Process Pressure :（-0.1～2）MPa
Accuracy: ±3mm
Signal Output : (4～20)mA HART/RS485 MODBUS
Explosion-Proof Grade: Ex ia IIC T1-T6 Ga/Ex d IIC T6 Gb
Protection Grade: IP68
Frequency Range: 26GHZ

PRODUCT DETAILS

Product introduction

0～20m 26G high frequency radar level sensor IP68 tank water level sensor

This series of HCDAR-6X adopted 26G high frequency radar sensor, the maximum measurement range can reach up to 70 meters. Antenna is optimized further processing, the new microprocessors have higher speed and efficiency can be done signal analysis, the instrumentation can be used for reactor, solid silo and very complex measurement environment.

Apparent dimension

Application case

HCDAR-66 is a water droplet type PTFE antenna, used in liquid, slurry, condensation occasions.

Technical data
