Product introduction

0-10v Water Pressure sensor High quality china 4-20ma Pressure transmitter

Pressure transmitter adopts the imported silicon piezoresistive sensor as the pressure measuring element, which is divided into simple type, sanitary type and industrial type.

The simple type pressure transmitter has Hirschman joint type and integrated cable type, both use single chip scheme. This chip is the special signal conditioning chip of pressure transmitter with high integration, high precision and good stability. 1 wire digital communication calibration , no potentiometer.

The sanitary type pressure transmitter planar diaphragm design solves the problem of common pressure transmitters which is unable to clean the dirt and impurities on pressure leading holes. It adopts the advanced temperature compensation and nonlinear correction technologies, so it is particularly suitable for the applications of food and pharmaceutical industries where request high level sanitary conditions.

The industrial pressure transmitter adopts high performance 24-bit AD converter, with backlight LCD , HART or RS485 communication as optional,  and three buttons on keyboard to fulfill the adjustment easily.

Selection and application

Product video

Application case

HCDP-12 sanitary pressure transmitter is specially designed for medicine, beer, milk warehouse, fruit juice and other medical and food fields of special products, in full compliance with the sanitary standards of the medical and food industry.The pressure of the measured medium is converted to 4~20mA DC standard signal through the high-reliability amplifier circuit.Sanitary pressure transmitter with flat membrane structure and a variety of leads can maximize to meet customer requirements, especially suitable for food and pharmaceutical, beverage processing and biological products industries.

Technical data
