HCDN-501 RF Admittance Level Transmitter

  • Application:Liquid,Solid

  • Measuring Range:10PF~5000PF

  • Allow Work Pressure:0.1~2MPa

  • Allowable Ambient Temperature:-35℃~65℃

  • Accuracy:<0.5% Actual Measured Value

  • Protection Grade:IP67

  • Signal Output:4-20mA(24VDC)

  • Housing:Die-Casting Aluminum

  • Cable Entry:M20*1.5

  • Explosion proof Grade: Ex d IIC T6 Gb/Ex ia IIC T6 Ga

PRODUCT DETAILS

Product introduction

0.1~2MPa RF admittance level Transmitter 10PF~5000PF 4-20mA 24VDC capacitance level sensor

The RF admittance level Transmitter is a continuous level measurement product based on the principle of RF admittance. The product has the advantages of good stability, high sensitivity and wide application range. It is developed on the basis of the traditional capacitive level meter and can be widely used in the continuous measurement of various liquid and solid level in petroleum, chemical, metallurgy, medicine, electric power, food, paper and other industrial fields. Especially in the environment of high temperature, strong corrosion, strong adhesion, and dust.





Apparent dimension


Application case

Common rod type, suitable for metal containers, measuring non-conductive media, due to installation and transportation limitations, the maximum measuring range is 3 meters, suitable for small tank level measurement. 24 VDC power supply.




Technical data
