Product introduction

-40～1200℃  0-60m 76 ~ 81GHz radar level sensor angle 3° ip68 High temperature resistant radar level transmitter

HCDAR-8X series radar level sensor is one kind of level measuring instrument which uses FMCW ( Frequency Modulated Continuous Wave ) special millimeter wave technology , the working frequency is 76-81Ghz. The signal output has options : 2 wires 4-20mA, 4 wires 4-20mA or RS485.  The max range can reach 120m, and the blind zone of 8cm. The antenna beam angle is about 3°,the outstanding performance makes it is workable for the accurate measurement of liquids, solids, and powder materials.

Product video

Application case

Add quartz isolation flange and heat dissipation device, suitable for liquid or solid measurement, antenna beam angle is small, suitable for high temperature, high pressure occasions.

Technical data
