HCDAR-80S radar water level sensor

  • Application: Liquid Measurement

  • Measuring Range: 0~20m

  • Beam Angle: 8°

  • Response Time: <0.6s ( Due To Parameter Setting)

  • Medium Temperature: (-40~120)℃

  • Process Pressure: (-0.1~2)MPa

  • Accuracy: <2mm

  • Signal Output: (4~20)mA HART

  • Working Frequency: (76 ~ 81)GHz

  • Explosion Proof Grade: Ex ia IIC T6 Ga

PRODUCT DETAILS

Product introduction

76 ~ 81GHz FMCW radar level sensor 4~20 mA radar water level transmitter

HCDAR-8X series radar level sensor is one kind of level measuring instrument which uses FMCW ( Frequency Modulated Continuous Wave ) special millimeter wave technology , the working frequency is 76-81Ghz. The signal output has options : 2 wires 4-20mA, 4 wires 4-20mA or RS485.  The max range can reach 120m, and the blind zone of 8cm. The antenna beam angle is about 3°,the outstanding performance makes it is workable for the accurate measurement of liquids, solids, and powder materials.




Product video



Application case

CAN MEASURE

VARIOUS LIQUIDS AND

COMPLEX WORKING CONDITIONS

Widely used in water conservancy, chemical, pharmaceutical, petroleum and other industries..



Technical data
