HCUS-500 Explosion-proof ultrasonic liquid level sensor

  • Application:Solids,Liquids

  • Measuring Range:0~20m

  • Connection Process:Thread

  • Process Pressure:≤0.3MPa

  • Accuracy:0.5%-1.0%

  • Protection Grade:Display Meter IP67/Probe IP68

  • Signal Output:(4-20)mA Two Wire

  • Explosion-proof Grade: Ex d IIB T4 Gb

  • Ex ib IIB T6 Gb

PRODUCT DETAILS


Explosion-proof IP68 0-20m Ultrasonic liquid level transmitter

Ultrasonic level transmitter is a non-contact, high reliability, cost-effective, easy to install and maintain level measurement instrument. It is a low-cost measuring device for measuring liquids, slurries and solids at industrial sites. It is widely used in water treatment, municipal, chemical, metallurgical and mechanical manufacturing industries.



1. None-contact continuous measurement, reduce maintenance.

2. Automatic power adjustment, gain control, temperature compensation.

3. Advanced detecting technology, rich software functions to adapt to a variety of complex environment.

4. Various output forms: programmable relay output, high-precision 4-20mA current output, rs-485 digital communication output.

5. Good directivity, strong penetrability, easy to obtain more concentrated sound energy to get further transmission distance.



HCUS-500 integrated ultrasonic level sensor, optional 2-wire 4-20mA specific aluminium alloy case for flameproof requirements.Suitable for higher grade applications.
